Dell PowerVault DL2200 Backup to Disk Appliance - Powered by Symantec Backup Exec 2010
Simplified Disk-to-Disk-to-Tape Data Backup and Recovery

Dell PowerVault DL2200 Backup to Disk Appliance - Powered by Symantec Backup Exec 2010

Dell Products
Dell Disk-To-Disk Backup
Dell PowerVault DL2200 Backup to Disk Appliance - Powered by Symantec Backup Exec 2010
Call for Pricing!
844-356-5140

SymantecOverview:

One of the industry's only integrated solution for faster disk-based backups and recoveries with optional deduplication that gets you up and running in less than 25 minutes.

Enjoy fast, easy data protection with the Dell PowerVault™ DL Disk-Based Backup Appliance powered by Symantec. One of the industry's premier integrated solutions for faster disk-based backups and recoveries, this integrated backup-to-disk appliance enables you to start protecting your critical data in less than 25 minutes.

  • Solution with deduplication option designed to be less expensive than similar tape solutions
  • Wizard-driven management capabilities
  • Continuous data protection for Exchange, file and SQL
  • Better storage management through archiving
  • Improved protection for virtual environments

Protect your data

Simplify the backup process while lowering your total cost of ownership with the only integrated hardware, software and services solution powered by Symantec™ Backup Exec 2010. Shipped with factory-installed Symantec software and a wizard-driven setup and management utility, the PowerVault™ DL Appliance enables you to set up and configure your storage space for immediate use, or even add more disks, in less than 25 minutes.

Deduplication Option Offers Savings, Simplicity and Adaptability

Even in this era of massive data growth, the PowerVault DL Appliance with Backup Exec 2010 deduplication option helps you optimize your storage capacity by limiting duplicate storage blocks and leaving only one copy of the data to be stored. Full indexing is retained, however, should the data ever be required again. The system is designed to be more cost-effective than similar tape solutions.

Integrated Tape Support

The PowerVault DL Appliance is available with the Dell PowerVault TL2000, TL4000 or ML6000 tape library integrated into the full solution. Take advantage of backup-to-disk for quick availability, and then transfer to tape from the same management console for off-site disaster recovery.

Built-in data deduplication reduces storage by up to 95%

Faster, More Reliable Backup

Not only can tape-based backups be complex and time-consuming, but they're also prone to failure and often exceed their backup window. Disk-based backup with the PowerVault DL Appliance powered by Symantec is fast and reliable, enabling you to restore with confidence.

Better than Virtual Tape Library

Virtual tape libraries (VTLs) are "point products" that can help fix backup and recovery bottlenecks in the short term. However, they are separate components that create silos of information and add management complexity. Virtual tapes have to be created, provisioned and managed from a separate interface, and VTL products lack alerting and reporting functions within the backup solution. The PowerVault DL Appliance is a native, disk-to-disk solution that eliminates the need for manual setup and management. It automatically and dynamically provisions disks and gives you proactive monitoring, alerts and reporting.

Distributed branch-office protectionRemote Backup, Management, Monitoring and Maintenance

You can use the PowerVault DL Appliance to back up data from remote offices to your data center, setting up backup tasks and policies, as well as performing system monitoring and maintenance from a central location. This makes the PowerVault DL Appliance the ideal backup solution for remote offices that do not have IT administrators on site.

Granular Recovery Technology for Speedy Restores

With Symantec's Granular Recovery Technology (GRT) for critical Microsoft applications, including Exchange, SharePoint (MOSS) and Active Directory, you can recover granular objects from a single-pass backup by simply browsing and selecting it. GRT lets you recover specific items, such as public folders and individual mailboxes, email messages, attachments and calendar items, without a time-consuming full restore.

Integration between archiving and backup

Improving archiving complements backup by helping companies identify what to store, what to delete and when to move older data to secondary systems while ensuring fast discovery and recovery of older data. The DL Appliance powered by Symantec provides the options to integrate archiving and backup, helping customers to control storage costs and recovery times. The DL Appliance with Backup Exec 2010 Agent for Enterprise Vault now supports Enterprise Vault 10 beta backup, recovery and migration. Additionally, the Backup Exec Archive Option for Exchange now includes Virtual Vault, allowing users to access archived emails directly from within Outlook.

Continuous Data Protection for Exchange and FileContinuous Data Protection for Exchange and File

The PowerVault DL Appliance powered by Symantec Backup Exec 2010 continuously protects Microsoft® Exchange and file data by backing up changes to the disk as they occur. Not only does this improve overall data protection, but it also reduces administrative complexity by eliminating the need for full, incremental or differential backups for Exchange data.

Protection for Desktops and Laptops
The Desktop and Laptop Option (DLO) with Backup Exec 2010 lets you automatically sync and protect multiple desktops and laptops using a network share. You can choose continuous, scheduled or manual backups through an intuitive interface that lets you access your latest data, even when you are on the road.

Protection for VMware Virtual Machines

Licensing requirements can make managing backups on virtual machines difficult and expensive. The PowerVault DL Appliance powered by Symantec™ Backup Exec 2010 incorporates award-winning technology for virtual machine protection. The Agent for VMware Virtual Infrastructure includes protection for an unlimited number of guests on an individual ESX host. In addition, Backup Exec 2010 leverages several VMware technologies, including VMware Consolidated Backup (VCB), that make backing up and restoring virtual machines faster and easier.

The DL Appliance powered by Symantec’s Backup Exec 2010 delivers improved backup and deduplication performance in virtualized environments. The new “V-Ray” technology embedded into the core solution gives customers x-ray vision to easily see, protect, and recover their virtual machines with the same solution that protects their physical environments. Additionally, Symantec’s Backup Exec Management Plug-in for VMware is now part of the standard agent for VMware providing Backup Exec management through vCenter.

Key Benefits:

Up and running in less than 25 minutes

Configuring homegrown backup-to-disk solutions can be difficult, time consuming, prone to errors, and expensive. Dell has simplified the backup process by offering one of the industry's first and only integrated hardware, software, and services solution powered by Symantec Backup Exec™ 2010 software. This integrated backup to disk appliance with target and source based deduplication is a cost-effective way to reduce total cost of ownership.

Dell PowerVault™ DL Backup to Disk Appliance – Powered by Symantec comes factory installed with Backup Exec™ 2010 R3 software, plus a unique wizard-driven setup and management utility. Integrated automated dynamic disk provisioning configures and sets up the disks for immediate use.

Set it up, configure storage, add more disks — it only takes a few clicks. PowerVault DL Appliance solutions are fully tested and validated, sure to work together, and you can deploy them quickly.

Industry leaders Dell and Symantec co-developed this offering to get you up and running fast with a tested solution that offers easier management. It's an ideal way for any IT department to achieve fast, reliable backups and restores. It's disk-based backup simplified by Dell.

Reliable disk-based backup and faster restores than tape

Managing tapes can be complex and time consuming. Backups to tape often exceed their backup window, and tape-based backups can fail. Disk-based backup with the PowerVault DL Appliance – Powered by Symantec Backup Exec can reduce cost and time associated with with tape-based backup, and reduce backup time, helping you meet your ever shrinking backup windows.

Archiving technology with the benefits of deduplication

The DL Appliance powered by Symantec Backup Exec 2010 integrates new archiving technology by utilizing Symantec Enterprise Vault for Exchange and Files server environments. This technology copies data from the backup source off to the archive "vault" where it's indexed – thus avoiding any performance impact on the source server. Archived data is then deleted on the Exchange or File system source. This can improve server performance, reduce backup times and keep Exchange and File server storage at predictable levels. During the archive process it can extended the "deduplication everywhere" savings to secondary storage environments by delivering the benefits of deduplication to the archive environment as well, which can allow administrators to easily consolidate data and maximize disk as archive storage for management and resource savings.

Better than VTL

Virtual Tape Libraries (VTLs) are "point products" that can help fix backup and recovery bottlenecks in the short run. But they're also separate "boxes" that create silos of information and add management complexity. Virtual tapes have to be created, provisioned, and managed, and VTL products lack alerting and reporting within the backup solution. The PowerVault DL Appliance is a native, disk-to-disk solution that is designed to eliminate the need for manual setup and management. It automatically and dynamically provisions disk, invisibly to the user, and gives you proactive monitoring, alerts, and reporting.

Integrated tape support

The PowerVault DL Appliance is available with the Dell PowerVault TL2000, TL4000, or ML6000 tape library integrated into the full solution. Take advantage of backup-to-disk for quick availability then transfer to tape from the same management console for offsite disaster recovery. It is the first of Dell's TierDisk family of products, designed to provide cost-optimized solutions for secondary storage environments for data protection and data management.

Easy to understand virtual disk layout options

The PowerVault DL Appliance allows the user to choose between several options during their initial set up within the First Time Boot Utility. You can choose between extra redundancy or more capacity (RAID-6 virtual disks or RAID-5), as well as the presence or absence of a hot-spare. This option to configure gives you more freedom to configure the DL Appliance to meet your specific needs.

Remote backup, management, monitoring, and maintenance

Your data center administrators can use the PowerVault DL Appliance to backup data from remote offices to the data center. Administrators can set up backup tasks and policies and do system monitoring and maintenance from a central location. This makes the PowerVault DL Appliance the ideal backup solution for remote offices that don't have IT experts on-site. You can also use the PowerVault DL Appliance's remote backup and management features to create a disaster recovery solution, when you transfer data from your data center to another PowerVault DL Appliance at a secondary location.

Granular recovery technology for speedy restores

With Symantec Backup Exec's patent-pending Granular Recovery Technology (GRT) for critical Microsoft applications, including file, Exchange, SharePoint (MOSS), and Active Directory, your administrator can recover granular objects from a single-pass backup by simply browsing and selecting it. GRT lets you recover specific items such as public folders and individual mailboxes — even individual Emails, attachments, and calendar items — all without a timeconsuming full restore.

Protection for VMware virtual machines with low cost and complexity

Managing backups on virtual machines can be difficult and expensive due to licensing requirements. The PowerVault DL Appliance – Powered by Symantec Backup Exec 2010 incorporates award-winning technology for virtual machine protection. The Agent for VMware Virtual Infrastructure includes protection for an unlimited number of guests on an individual ESX host. In addition, Backup Exec 2010 leverages VMware VStorage APIs for offhost backup of VMs.

The DL Appliance with Symantec Backup Exec 2010 has improved backup performance by using a new "V-Ray" technology. This is embedded into the core solution and gives customers an x-ray like vision to easily see, protect, and recover their virtual machines with the same solution that protects their physical environments.

Symantec's Backup Exec Management Plug-in for VMware is now part of the standard agent for VMware providing Backup Exec management through vCenter. This provides insight into VMware backups to protect status view of all VM's, identify the last time you ran your backup, identify if it was a full or incremental or differential and when the next one is scheduled. In addition, this Plug-in can give you a view into unprotected machines.

Protection for desktops and laptops

Backup Exec's 2010 Desktop and Laptop Option (DLO) lets users automatically protect multiple desktops and laptops via a network share. DLO lets users choose continuous, scheduled, or manual backups and provides an intuitive interface that lets users access their most up-to-date data whether they're in the office or on the road.

New security layer

The way the new security layer works is it uses a standards based solution already used by the World Wide Web. Transport Layer Security (TLS) and it's older sibling, Secure Sockets Layer (SSL) provides support from the agent to the server, providing an extra layer of security for customers that transmit backup data across the WAN or to a private cloud. The new security layer enables mutual authentication via certificates, and can help assures attackers are kept out of sensitive backup operations.

Lifecycle storage solution support

Choosing the right backup solution is an important step in keeping your critical information safe. Storage Consulting and Deployment from Dell can help you implement, manage, and optimize storage infrastructure as well as backup and recovery in a cost-effective manner, helping to reduce the risk associated with ineffective data management and reduce complexity while improving information availability. Having the right support is also important. Dell ProSupport for IT provides businesses of all sizes with flexible, reliable, and easier support solutions.

The Dell ProSupport* for IT service model was designed for IT professionals like you. It provides:

  • 7x24 direct access to Dell Expert Centers
  • Fast-track dispatch for Dell-certified technicians
  • Escalation management through Dell's Global Command Centers

The globally consistent, customer-driven Dell ProSupport for IT portfolio includes proactive support options that align to how you use technology. These enhanced offerings can help you protect your investment, reduce risk, manage complexity, enhance productivity, and guard your sensitive data.

Product Views:

Gallery
Gallery

Front View
Front View

Front Open (12 Drives) View
Front Open (12 Drives) View

Rear View
Rear View

Technical Specifications:

PowerVault DL2200 Backup to Disk Appliance
Processor - Value Series 1 X Intel Xeon E5620, 2.4Ghz, 12MB Cache
Processor - Performance Optimized 2 X Intel Xeon E5620, 2.4Ghz, 12MB Cache
Memory Available with 12GB, 24GB, 32GB or 48GB
Graphics Matrox G200
Internal Storage 2 X 500GB2 , Near Line SAS Drives in Hardware RAID 1 Configuration for the Operating System and Application
6 or 12 of 500GB, or 1TB, 2TB or 3TB, Near Line Drives in Hardware RAID 5 or RAID 6 Configuration for the data
Optional Expansion with SAN Support for MD3000i, AX4-5 Fiber Channel array or EqualLogic PS Series arrays
External Storage Connectivity Available through 1 or 2 PERC 6/E
Tape Connectivity 6Gbps SAS HBA; Emulex or QLogic HBAs
Networking Dual-embedded Broadcom NetXtreme IITM 5708 Gigabit6 Ethernet NIC with fail-over and load balancing
Operating System Windows Server 2008, R2 Standard; Factory Installed OS
Systems Management iDRAC Express
Remote Management DRAC
Physical Dimensions 2U rack-mountable chassis
26.17" (66.46 cm) D x 17.53" (44.52 cm) W x 3.42" (8.67 cm) H with bezel attached
Rack Weight 57.54 lbs. (26.1 kg), maximum configuration
Ports Rear: 2 x USB 2.0, 1 x serial connector, 1 x video connector
Power Energy Smart- Two hot plug high efficient 750W PSUs
Security Optional TPM Module
Optional Absolute Computrace software
Regulatory Regulatory Model: E13S (12 Hard Drives Configuration)
Regulatory Type: E13S001 (12 Hard Drives Configuration)
Optional Expansion with PowerVault MD1200
Hard Drives 1XH800 for connecting up to 8 MD1200 Enclosures (i.e. a total of 96 Drives). One additional H800 card available for purchase - to connect 8 additional MD1200 enclosures (for a total of 192 Drives)
Maximum Usable Capacity Up to 464 TB of usable space, using 3TB hard drives
Maximum Backup Capacity Up to 27 TB of usable disk space (using 3TB hard drives)
*Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions.

Software:

The software for PowerVault DL Appliance – Powered by Backup Exec 2010™ is available in two options:

  • Backup Exec 2010 R3 DL Edition: Includes Factory Installed Backup Exec Media Server (including the licensing for Continuous Protection Server and connectivity to a single tape drive) and licenses for backing up 2 Windows File Server Agents. This comes with 1 or 3 Years of Software maintenance included.
  • Backup Exec 2010 R3 DL Edition with Deduplication: Includes Factory Installed Backup Exec Media Server with deduplication (including the licensing for Continuous Protection Server and connectivity to a single tape drive), and licenses for backing up 2 Windows File Server Agents. This comes with 1 or 3 Years of Software maintenance included.

Additional available licenses:

  • BE 2010 Windows Server Agents: Includes Licenses for backing up two Windows Files Servers.
  • BE 2010 Linux/Unix Server Agents: Includes Licenses for backing up two Linux/Unix Files Servers.
  • BE 2010 Email Protection Agents: Includes Licenses for backing up two Email (Exchange or Lotus Domino) Servers.
  • BE 2010 Database Agents: Includes Licenses for backing up two Database (SQL, Oracle, Sharepoint, and Active Directory) Servers.
  • BE 2010 Virtual Agents: Includes Licenses for backing up two Virtual Servers (Vmware and/or HyperV). Only one agent is required for every Physical server, with support for unlimited number of virtual servers on the physical server.
  • BE 2010 Archiving Agents: Includes Licenses for archiving One File Server or Email Server (with up to 50 additional mailboxes).
  • BE 2010 Library Expansion Option: Includes Licenses for Adding Two additional Tape Libraries to the media server.
  • BE 2010 Advanced Database Option: Includes Licenses for protecting an advanced database (Oracle RAC or SAP).
  • BE 2010 Central Management Addon Pack: Includes the license for Central Admin Server Option (the feature allows for centralized management of multiple DL Media Servers).

Services:

Having the right backup solution is key to protecting your critical information. So is having the right support. Dell ProSupport™ is a portfolio of globally consistent, customer-driven support services that provides businesses of all sizes with flexible, reliable and easier support solutions.

Dell ProSupport starts with the Dell ProSupport for IT service model designed for IT professionals like you. Dell ProSupport for IT provides:

  • 24x7 Direct access to Dell Expert Centers
  • Fast-track dispatch for Dell certified technicians
  • Escalation management through Dell’s Global Command Centers

Next, Dell ProSupport Options align to the way you use technology — rapidly responding to your needs, protecting your investment, productivity and sensitive data, and providing enhanced proactive support services to reduce the risk and complexity of managing your infrastructure.

Speed of Response Protection Premium Proactive
Mission Critical — Perfect for server and storage environments where avoiding unplanned downtime and reducing recovery time through priority response are a must. The package includes priority 4-hour on-site2 service or optional 2-hour response with 6-hour hardware repair, Dell's proven Critical Situation process and emergency dispatch. Keep Your Hard Drive — Enables you to control your sensitive data by retaining your hard drive and helps you comply with current data privacy regulations to help mitigate risks associated with regulatory or civil liabilities. Enterprise-Wide Contract — Provides enhanced proactive capabilities through:
  • Designated Service Delivery Manager
  • Performance benchmarking and custom reporting
  • Planning and assessments

Proactive Maintenance — Maximizes the availability and stability of your infrastructure proactively. The package includes a detailed system assessment and implementation of driver or firmware updates and upgrades for your server or storage systems.

Remote Advisory Options —Provides telephone and Internet access to technical expertise for specialized applications and solutions such as Microsoft® Exchange, Virtualization and more.

Basic Hardware Warranty
Basic Support
Ideal for nonessential application environments. This service offers business-hour, phone-based support* for hardware-only issues with Next Business Day On-Site Service following completion of phone-based troubleshooting.
Additional Service Offerings
Comprehensive Storage Training and Certification
Through comprehensive storage training courses, Dell provides expertise in implementing Dell storage into an existing IT infrastructure. If you are interested in validating or maintaining your skill sets for company compliance, the Dell Certified Network Storage Networking Professional Certification path is available.

Backup and Recovery
To sustain the continued operation of your storage solution, you should engineer availability, security and reliability into every process from the outset. Dell can provide backup and recovery solutions that help ensure adequate procedures are in place to minimize or avoid data loss.

Storage Consolidation
Our storage experts analyze existing infrastructure, operational practices and technical readiness to develop a roadmap for conducting a storage consolidation. They will also develop a detailed consolidation deployment plan as well as a validated and refined solution design.
