Dell EMC PowerEdge XE8545
AI infrastructure without compromise

Dell Storage Products
Dell PowerEdge Specialty Servers
Dell EMC PowerEdge XE8545 Server
#PE-XE8545
Get a Quote!

More pricing below, click here!

Overview:

The Dell EMC PowerEdge XE8545 is a supercharge your compute performance with a 2 socket, 4U system designed to optimize the latest industry technologies. Develop, train, and deploy cutting edge machine learning models, accelerate complex high-performance computing workloads or host accelerated virtualization services.

Optimized CPU & GPU performance

The XE8545 uses the highest core count AMD CPUs with the highest powered NVIDIA A100 Tensor Core GPUs for a large and powerful range of processing needs.

  • Combine the highest core counts (128) of the new generation of AMD EPYC processors and the most GPU memory and bandwidth available today to break through the bounds of AI computing.
  • Host multi-tenant environments using a flexible set of virtualization options: NVIDIA’s vGPU software and their new Multi-Instance GPU (MIG) capability.
  • Choose between 400 W and 500 W GPU options, while maintaining air-cooled (35C/25C) efficiency
  • NVIDIA-Certified System tested for performance, manageability, security, and scalability

Accelerated I/O throughput

The XE8545 stands out by combining all its components - NVLink, PCIe Gen 4.0, and NVMe SSDs to push the boundaries of data flow and computing possibility.

  • Achieve 6-7 the machine learning performance (2x the HPC performance) over today’s accelerators with PCIe Gen 4 A100 SXM4 GPUs with the highest peer to peer bandwidth (600Gb/s) in a low latency switchless design.
  • Improve machine learning training with 20x performance gain based on sparsity-enabled matrix multiplication and 600GB/s bandwidth for GPU-GPU communication, 2x more than the previous generation.

Simplified management

The XE8545 simplifies data center operations with the full OpenManage stack, standard rack depth, and air cooling.

  • Manage your data center efficiently and consistently with full iDRAC compliance and Open Management Enterprise (OME) support.
  • Readily integrate this innovative technology into your data center with a standard depth rack, and air-cooled (35C) chassis, avoiding expensive costs.

Fortify your data center with integrated security

Every PowerEdge server is designed with a cyber resilient architecture, integrating security deeply into every phase in the lifecycle, from design to retirement.

  • Enhance security with platform enablement of AMD Secure Memory Encryption (SME) and Secure Encrypted Virtualization (SEV).
  • Operate your workloads on a secure platform anchored by cryptographically trusted booting and silicon root of trust.
  • Maintain server firmware safety with digitally signed firmware packages.
  • Detect and remediate unauthorized or malicious change with drift detection and system lockdown.
  • Securely and quickly wipe all data from storage media including hard drives, SSDs and system memory with System Erase

Features:

Your innovation engine

The Dell PowerEdge XE8545, powered by 3rd Generation AMD EPYC processors, is a dense compute node to address massive compute at scale.

Built for Your Most Demanding Workloads from the Edge to Multi-Cloud

PowerEdge XE is the first server family purpose-built for complex, emerging workloads that require high performance and large storage. These robust servers deliver the reliability and security for demanding applications inside traditional data centers or in extreme conditions stretching from outside the data center to the harsh edge environment of the IT infrastructure.

  • Rapidly respond to data growth by meeting the fluctuating demands of compute, latency and bandwidth
  • Monitor system health health accurately with unified systems management
  • Protect your customers and your business with a deep layer of defense built into the hardware and firmware

Systems Management and Security Solutions


OpenManage systems management

The Dell Technologies OpenManage systems management portfolio helps tame the complexity of your IT environment with tools and solutions to discover, monitor, manage, update, and deploy your PowerEdge infrastructure.

Intelligent Automation

PowerEdge and OpenManage solutions integrate tools across the portfolio to help organizations automate the server lifecycle, optimize operations, and scale efficiently.

Built-in security

PowerEdge servers are made with a cyber resilient architecture that builds in security at every phase of the product lifecycle, from the silicon root of trust and secured component verification, to signed firmware and drift detection, to BIOS recovery.


Technical Specifications:


Dell EMC PowerEdge XE8545 Specifications
CPU Two 3rd Generation AMD EPYC processors (280 W) with up to 64 cores per processor
Memory
  • 32 x DDR4
  • Bandwidth up to 3200 MT/s
Accelerators
  • 4 x NVIDIA A100 GPUs with NVIDIA NVLink
  • Options: 40 GB/400 W or 80 GB/500 W
Front Storage
  • 10 x 2.5” Hot Plug SAS/SATA
  • Up to 8 x 2.5” NVMe
Controllers BOSS S1.5, H745
I/O ports
  • 1 x PCIe Gen4 LP (x16)
  • 1 x PCIe Gen4 FH (x16)
  • 1 x PCIe Gen4 FH (x16) or 2 x PCIe Gen4 FH (x8)
Thermal Air Cooled Up to 35C for 400 W GPUs or 25C for 500 W GPUs
Fans 12 x Front Hot Plug Fans, 6 x Internal Fans (CPU)
Embedded Management
  • iDRAC9
  • iDRAC Direct
  • Quick Sync 2.0
OpenManage Software
  • iDRAC9 Enterprise
  • Power Manager
  • SupportAssist
  • Update Manager
Power Supplies 4 x Hot-plug redundant 2400 W AC Power Supply
Rack Height 4U
Ports
  • Front: 1 x USB 2.0 – iDRAC dedicated
  • Rear: 1 x USB 3.0, 1 x USB 2.0
Security
  • Cryptographically signed firmware
  • Secure Boot Secure Erase
  • Silicon Root of Trust
  • System Lockdown
  • TPM 1.2/2.0, TCM 2.0 optional
  • Secure Memory Encryption
  • Secure Encrypted Virtualization
Dimensions Depth: 810 mm Width: 447 mm Height: 86.8 mm
Rack Unit 4U Rack Server
Embedded NIC 2x 1GbE LOM
Networking Options OCP x16 mezz 3.0
Operating Systems & Hypervisors
  • Ubuntu
  • Windows Server with Hyper-V
  • Red Hat Enterprise Linux
  • VMware ESXi
OEM-ready version available From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.

Support & Services:

Dell Technologies offers complete end-to-end services

Optimizing the IT lifecycle is vital. We have expert services for all lifecycle phases that save you time and resources, reduce effort, and improve your IT experience.


Proactive Management and Monitoring (no charge)

Consulting

Consulting services give expert guidance to help you grow, optimize and transform your IT environment at your own pace and budget. Dell employ a broad range of certified consultants and engineers, backed by program management teams, who can deliver deep technical expertise. Dell gives you the confidence that your project will be done right and on time.


Support Services


Support

Gain the freedom to focus on your business transformation with the support expertise and insights Dell is known for across the globe. Choose the right support based on the criticality of specific systems with available automated predictive analysis, collaborative third-party assistance and a Technology Service Manager.


Deployment Services


Deployment

ProDeploy Enterprise Suite helps you get more out of technology starting on day one. Residency Service provides ongoing transition assistance to accelerate adoption. Trust our experts to lead deployments from basic hardware installations through planning, configuration and complex integrations to help you achieve business outcomes today and tomorrow.


Training & Certification

Training & Certification

Education Services offers an expansive suite of training services with multiple delivery methods, including instructor-led, self-paced online and virtual instructor-led training. With comprehensive and flexible training programs, we make it easy to ensure your staff has the skills they need to successfully manage and utilize your new technology to its full potential.


Documentation:

Dell EMC PowerEdge XE8545 Datasheet (.PDF)

Pricing Notes:

  • Pricing and product availability subject to change without notice.
