Dell EMC PowerEdge R240
4-bay entry-level 1U rack server

Dell Storage Products
Dell PowerEdge Rack Servers
Dell EMC PowerEdge R240 Rack Server
#PE-R240
Get a Quote!

More pricing below, click here!

Overview:

The Dell EMC PowerEdge R240 is an affordable single-socket 1U rack server designed for small businesses and service providers. It increases performance, ability to scale, and simplify your IT with an entry-level 1U rack server designed for web hosting and multi-purpose applications.

Designed for budget-conscious businesses

The Dell EMC PowerEdge R240 designed for dense environments is the ideal solution for budget-conscious businesses. The R240 offers features to support your demanding and growing business needs.

Simple to install, manage and deploy

The Dell OpenManage portfolio offers innovations that simplifies management tasks, making IT operations efficient and cost-effective throughout the server lifecycle.

Keep your data safe

Every PowerEdge server is made with a cyber-resilient architecture, building security into the server’s entire life cycle. Dell EMC is laser-focused on security (from design to end-of-life) to ensure trust and deliver worry-free, secure servers.

Features:

Designed for the budget-conscious businesses

Enterprise-class features at prices you can afford

  • Increase performance with up to 100% higher core counts. Customers can choose a 4-, 6-, or 8-core Intel® Xeon® E-2200 processor
  • Address data sets with up to four DDR4 DIMMs and with a maximum of 64GB of RAM
  • Reduce operational costs with multi-vector cooling that automatically calculates and delivers the proper airflow needed for optimal cooling

Adaptable to meet your evolving IT needs

Scale with reliable and security features you can depend on

  • Increase compute performance and the ability to run multiple applications at the same time, by choosing either a 4-, 6-, or 8-core Intel Xeon E-2200 processor
  • Harness data growth with up to four 3.5" hot plug or cabled HDDs
  • Address data sets with up to four DDR4 DIMMs and with a maximum of 64GB of RAM

Simplify your IT infrastructure

Reduce the time and effort to manage IT environments by automating everyday tasks.

  • Deploy multiple servers with iDRAC Group Manager, a built-in “one to many console”
  • Remotely access your servers anywhere, anytime from your mobile device with OpenManage Mobile (with OpenManage Enterprise)
  • Resolve issues with up to 72% less IT effort using automated proactive and predictive technology from ProSupport Plus and SupportAssist.

Systems Management and Security Solutions


OpenManage systems management

The Dell Technologies OpenManage systems management portfolio helps tame the complexity of your IT environment with tools and solutions to discover, monitor, manage, update, and deploy your PowerEdge infrastructure.

Intelligent Automation

PowerEdge and OpenManage solutions integrate tools across the portfolio to help organizations automate the server lifecycle, optimize operations, and scale efficiently.

Built-in security

PowerEdge servers are made with a cyber resilient architecture that builds in security at every phase of the product lifecycle, from the silicon root of trust and secured component verification, to signed firmware and drift detection, to BIOS recovery.


Technical Specifications:


Dell EMC PowerEdge R240 Specifications
Processors 1 processor from the following: Intel® Xeon E-2200 product family, Intel Pentium, Intel Core i3, Intel Celeron
Memory 4 x DDR4 DIMM slots, Supports UDIMM, up to 2666MT/s, 64GB Max. Supports registered ECC
Storage controllers
  • Internal controllers: PERC H730P, H330, HBA330
  • Software RAID: PERC S140
  • External controllers: 12Gbps SAS HBA
  • Internal Boot Optimized Storage Subsystem (BOSS): 2 x M.2 240GB (RAID 1 or No RAID) or 1 x M.2 240GB (No RAID only)
  • Internal Dual SD Module: 2x microSD (16GB, 32GB or 64GB) or 1x microSD (16GB, 32GB or 64GB)
Drive bays Front bays:
  • Up to 4 x 3.5 cabled SATA, SAS (optional) or SSD*
  • Up to 4 x 3.5 or 2.5 hot-plug SATA, SAS (optional) or SSD*
Power supplies Single 250W (Bronze) or 450W (Platinum) power supply
Dimension
  • Chassis width: 434.00mm (17.08 in)
  • Chassis depth: 573.596mm (22.58 in) (3.5” HDD config)
  • Chassis weight: 12.2 kg (26.89 lb.)
Form Factor 1U rack server
Embedded management
  • iDRAC9
  • iDRAC Direct
Bezel Optional bezel or security bezel
OpenManage Software
  • OpenManage Enterprise
  • OpenManage Power Manager
  • OpenManage Mobile
Integrations and Connections Integrations:
  • Microsoft System Center
  • VMware vCenter
  • BMC Truesight (available from BMC)
  • Red Hat Ansible

Connections:

  • Nagios Core & Nagios XI
  • Micro Focus Operations Manager i (OMi)
  • IBM Tivoli Netcool/OMNIbus
Security
  • TPM 1.2/2.0 optional
  • Cryptographically signed firmware
  • Silicon Root of Trust
  • 2 x PCIe Gen 3.0 slots:
    • One x8 slot low-profile, half-length with x4 slot width
    • One x16 slot low-profile/full-height, half-length with x8 bandwith
Supported operating systems
  • Citrix XenServer
  • Microsoft Windows Server with Hyper-V (2016 and 2019)
  • Red Hat Enterprise Linux
  • Ubuntu Server LTS
  • SUSE Linux Enterprise Server
  • VMware ESXi
OEM-ready version availabe From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.

Support & Services:

Dell Technologies offers complete end-to-end services

Optimizing the IT lifecycle is vital. We have expert services for all lifecycle phases that save you time and resources, reduce effort, and improve your IT experience.


Proactive Management and Monitoring (no charge)

Consulting

Consulting services give expert guidance to help you grow, optimize and transform your IT environment at your own pace and budget. Dell employ a broad range of certified consultants and engineers, backed by program management teams, who can deliver deep technical expertise. Dell gives you the confidence that your project will be done right and on time.


Support Services


Support

Gain the freedom to focus on your business transformation with the support expertise and insights Dell is known for across the globe. Choose the right support based on the criticality of specific systems with available automated predictive analysis, collaborative third-party assistance and a Technology Service Manager.


Deployment Services


Deployment

ProDeploy Enterprise Suite helps you get more out of technology starting on day one. Residency Service provides ongoing transition assistance to accelerate adoption. Trust our experts to lead deployments from basic hardware installations through planning, configuration and complex integrations to help you achieve business outcomes today and tomorrow.


Training & Certification

Training & Certification

Education Services offers an expansive suite of training services with multiple delivery methods, including instructor-led, self-paced online and virtual instructor-led training. With comprehensive and flexible training programs, we make it easy to ensure your staff has the skills they need to successfully manage and utilize your new technology to its full potential.


Documentation:

Dell EMC PowerEdge R240 Datasheet (.PDF)
